PI7553PHTSU 2.0

SlimHob®
3 preset cooking programmes
AutoBridge

Specification

FEATURES

Autobridge Yes

Rapid preheating Yes

Automatic pot position detection Yes

Hob&Go Yes

Bridge power 2,7/3,7

Bridge bay size (mm) 185x366

ChildLock Yes

CookAdapt Yes

Direct Touch Yes

Energy saving Yes

Flexi Space Yes

Hob finish No bevelled

Front left heating zone dimension (cm) 20

Left front zone energy consumption FL 188.9 Wh/kg

Front left heating zone power rating (kW) 2.3/3

Left front zone type FL Induction

Rear left heating zone dimension (cm) 16

Left rear zone energy consumption RL 188.9 Wh/kg

Rear left heating zone power rating (kW) 1.4/2.1

Left rear zone type RL Induction

Middle zone energy consumption MID 188.9 Wh/kg

Middle heating zone power rating (kW) 2.3/3

Middle zone type MID Induction

Minute minder Yes

Number of Booster 5

Bridge zones 1

Number of power levels 9

Overflow detection Yes

Overheat detection Yes

Pause function Yes

Power Choice Yes

Residual heat indicator Yes

Front right heating zone dimension (cm) 16

Right front zone energy consumption FR 188.9 Wh/kg

Front right heating zone power rating (kW) 1.4/2.1

Right front zone type FR Induction

Rear right heating zone dimension (cm) 16

Right rear zone energy consumption RR 188.9 Wh/kg

Rear right heating zone power rating (kW) 1.4/2.1

Right rear zone type RR Induction

ø 16 cm with Power Booster 3

ø 20 cm with Power Booster 1

ø 25 cm with Power Booster 1

Slider control Yes

SlimHob - Installation in a thin table top Yes

Small object detection Yes

Temperature limiter Yes

3 warming levels Yes

Auto switch off Yes

Timer Yes

Hob energy consumption 188.9 Wh/kg

Control type Slider

Equipment

Power indicator lamp Yes

Technical data

Frequency 50Hz / 60Hz	Can be built flush with the top Yes	Connection type 400_V_3N_400_V_2N
Cut out size - depth 49 cm	Cut out size - width 75 cm	Display color Red
Edge finish C-cut	Gross volume 0.0668 m³	Total power of hob 10.5 kW
In-furniture depth 5 cm	Net depth 52.2 cm	Net height 5.4 cm
Net weight 11.5 kg	Net width 78 cm	Number of heating elements 5
Position Of Connection Cable Right - rear	Power Supply Voltage 400V	Power Supply Voltage 220_240_380_415
Hob type Induction
